Combined Laminated-IGU
|
Technical Specifications |
| Thickness of Single Glass |
4mm | 5mm | 6mm | 8mm | 10mm | 12mm, etc. |
|
Spacer |
6A | 9A | 12A | 16A | 20A | 23A | 27A | Custome Made |
| Layers |
Double or Triple |
| Filling |
Air or Argon |
| Size |
Custome Made |
| Color |
Custome Made |
|
Packing |
Steel Frame, Wooden Frame, or Plywood Crate Protection Packaging to Prevent any Damage |
Features
- Dual Safety Layer: 1.52mm PVB interlayer + 16mm argon-filled cavity meets safety standards.
- Hybrid Insulation: Low-E coating + thermal spacer achieves U-value 0.48 W/(m²·K) with 85% solar heat gain control.
- Impact Resistance: Withstands 227g steel ball 9m drop test.
- Acoustic Performance: Triple asymmetric glazing (6+12A+6+12A+8) reaches STC 47.
- UV Blocking: 99.9% UV cut-off rate with 78% visible light transmittance.
- Hurricane Proof: Passes 4.5kg 2x4 impact at 24m/s.
- Fire Safety: 60-minute integrity with fire-rated configuration.
- Self-Cleaning Surface: Outer pane with photocatalytic coating.
- Custom Configuration: 6-36mm variable cavity + 3-19mm glass thickness combinations.
- Pressure Equalization: Micro-ventilation system maintains 15Pa pressure balance.
- Lifetime Warranty: 25-year seal failure protection.
|
