Fixed Window
|
Technical Specifications |
| Open Style |
N/A |
|
Profile |
Aluminum | uPVC | Aluminum-Clad Wood | Steel | Timber |
| Glazing |
DGU | TGU | BBG | Tempered | Laminated | Low-E | Insulated | Frosted |
| Sealing System |
High Quality EPDM or Silicone Sealant |
| Size |
Custome Made |
| Color |
White | Grey | Brown | Black | Custome Made |
|
Packing |
Pearl Cotton or Wooden Crate Protection Packaging to Prevent any Damage |
Features
- Maximum Airtightness: Continuous thermal barrier achieves 0.05 m³/(m·h) air leakage rate - 3x tighter than operable windows.
- Structural Integrity: Aluminum framing withstands 5000Pa wind load.
- Thermal Performance: Polyamide thermal break delivers U-value 0.68 W/(m²·K).
- Acoustic Excellence: 52dB STC rating with 44mm triple-glazed asymmetric configuration.
- Seamless Design: Frameless option provides 98% visible glass area for panoramic views.
- Weatherproof Construction: Quadruple silicone seals achieve IP68 rating.
- UV Control: Low-E coating blocks 99% UV radiation with 82% VLT.
- Condensation-Free: Thermal spacer maintains 12°C edge temperature.
- Custom Shapes: CNC-bent frames support circular/triangular geometries (R300-R6000mm).
- Anti-Corrosion: Aluminum alloy profiles with high properties are suitable for coastal applications.
- Self-Cleaning Option: Photocatalytic outer surface reduces maintenance.
- Fire-Rated Version: 60-minute integrity with glazing.
|
