Arch Window

Technical Specifications
Open Style	Open Outward \| Open Inward
Profile	Aluminum \| Aluminum-Clad Wood \| Steel
Glazing	DGU \| TGU \| BBG \| Tempered \| Laminated \| Low-E \| Insulated \| Frosted
Sealing System	High Quality EPDM or Silicone Sealant
Size	Custome Made
Color	White \| Grey \| Brown \| Black \| Custome Made
Packing	Pearl Cotton or Wooden Crate Protection Packaging to Prevent any Damage

Curved Frame Engineering: CNC-bent aluminum alloy profiles maintain precise arc geometry with R600-R6000mm radius range.
Thermal Performance: Plyamide thermal break achieves U-value 0.89 W/(m²·K) with triple EPDM seals.
Structural Integrity: Thicker frame is good for high withstands wind load.
Acoustic Solution: 48mm glazing cavity with asymmetric glass configuration reaches STC 44 rating.
Custom Geometry: Parametric BIM modeling supports elliptical/gothic/segmental arch configurations with 5° angular increments.
Dual Material Option: Aluminum exterior cladding + Timber interior.
Security System: 10-point multi-directional locking mechanism.
Condensation Control: Thermal spacer maintains 12°C edge temperature differentia.
Self-Cleaning Coating: Hydrophilic nano-layer reduces maintenance frequency by 70%.
