Bifolding Door
|
Technical Specifications |
| Open Style |
Folding Outward | Folding Inward |
|
Profile |
Aluminum |
| Glazing |
DGU | TGU | BBG | Tempered | Laminated | Low-E | Insulated | Frosted |
| Sealing System |
High Quality EPDM or Silicone Sealant |
| Size |
Custome Made |
| Color |
White | Grey | Brown | Black | Custome Made |
|
Packing |
Pearl Cotton or Wooden Crate Protection Packaging to Prevent any Damage |
Features
- Seamless Stacking: 6-panel system folds 180° with 85% opening width, requiring only 1/5 wall space compared to sliding doors.
- Structural Load Capacity: Thicker 6063-T6 aluminum profiles support 300kg/m² load.
- Thermal Break Innovation: Polyamide barrier achieves U-value 0.76 W/(m²·K) with dual silicone seals.
- Low-Friction Roller System: Bearings with self-cleaning tracks ensure 100,000+ cycles.
- Acoustic Performance: 44mm triple-glazed option reaches STC 42.
- Security Locking: 12-point shootbolt system.
- Custom Configurations: 2-12 panel options with 450-1200mm panel widths, RAL/NCS color matching.
- Corrosion Resistance: Aluminum alloy profiles with high properties are suitable for coastal applications.
- Fire Escape Compliance: Emergency release mechanism meets panic exit requirements.
- Energy Efficiency: Low-E glass + argon fill achieves SHGC 0.25.
|
